Ac175-265v Aircraft Warning Lights Aluminum Body

Ac175-265v Aircraft Warning Lights Aluminum Body

  • Ac175-265v Aircraft Warning Lights Aluminum Body
  • Ac175-265v Aircraft Warning Lights Aluminum Body
  • Ac175-265v Aircraft Warning Lights Aluminum Body
Ac175-265v Aircraft Warning Lights Aluminum Body
Product Details:
Place of Origin: China
Brand Name: Aina
Certification: CE, ROHS
Model Number: AN-SN-Airport
Payment & Shipping Terms:
Minimum Order Quantity: 10
Packaging Details: Carton
Delivery Time: 10 days
Payment Terms: T/T, Western Union, L/C
Supply Ability: 10000 pieces per day
Contact Now
Detailed Product Description
Light Source: LED Item Type: Signal Light
Input Voltage(v): AC175-265V Lamp Body Material: Aluminum
Warranty(years): 5 Cri (ra>): 85
Base Type: No Lamp Base Led Light Source: LED
Working Temperature(℃): -20 - 40
High Light:

ac175v aircraft warning lights

,

aluminum body aircraft warning lights

,

ac265v solar obstruction light

Aviation Obstruction Lights Helicopter Lifts Solar Signal Lights



OVERVIEW



Feature

High-intensity aviation obstruction lights are powered by AC 220V power supply, using three sets of C0B integrated light sources, through COB

Intelligent switching of backup light source technology and high transmittance optical glass lens converts the COB plane luminous body into a three-dimensional light source.

This aviation obstruction light integrates three sets of COB light sources and three sets of driving power sources, and adopts microcomputer detection program algorithm.

Control technology, the light source and driver are combined into three groups in an orderly manner, and three automatic switching of light source and driver can be realized through software optimization.

Function, whether the driving part or the light source is damaged during use, the obstruction light can effectively detect the damaged single

The element body and automatically switch to the standby circuit and light source to continue to work, thereby greatly extending the service life of aviation obstruction lights

, can effectively reduce the user's high-altitude maintenance and repair cycle.

This aviation obstruction light is an integrated intelligent synchronous flashing light. When installing, users only need to pass the CG-3 type produced by our factory.

When the photoelectric controller is connected to the AC 220V power supply, it can automatically turn off during the day and automatically turn on at night to realize automatic control.

It can also be controlled by the wiring of the GPS automatic obstacle light control box, so that multiple building groups can achieve synchronous flashing.

Ac175-265v Aircraft Warning Lights Aluminum Body 0Ac175-265v Aircraft Warning Lights Aluminum Body 1

Basic Specification

Input AC220V or solar version light intensity >200000CD
Life time of the Light source 3x50000 hours Light power 100w
Flash way white pulse flash flash cycle 40-60 times/minutes



Application

1. The height-limited or super-high buildings and structures protected by the airport clearance shall be provided with aviation obstruction lights and signs.

2. Artificial and natural obstacles that affect flight safety on the route and around the flight area shall be provided with aviation obstruction lights and signs

3. Towering and tall buildings and facilities on the ground that may affect flight safety shall be provided with aviation obstruction lights and signs and keep it normal.

Ac175-265v Aircraft Warning Lights Aluminum Body 2

Delivery & Warranty

Selling Unites: Single Item

MOQ: 1000 pieces for each model

Customization: Customized Logo -1000 pieces / Customized Package- 10000 pcs

Production time: 5-7 days for samples / 10-15 days for standard orders

Warranty: 2-3 years



After sales service

1. We will not refund without reason.

2. If some items are damaged during delivery due to some objective reasons, we will not refund in full. But we can accept a partial refund to compensate the damaged part.

3. If the product has quality problems, you can take pictures and videos for us. When we confirm, we will provide you with a satisfactory solution and return the damaged parts

4. If imitating a big brand product, please do not compare its quality with the original product. Because price determines quality.



Ac175-265v Aircraft Warning Lights Aluminum Body 3



Our Service

Enquiry and email will be replied within 24 hours.

OEM & ODM are welcome. Any customized design and logo are available.

We own purchase,Production and marketing team with abundant knowledge and 10 years operational experience in LED semiconductor lighting, will provide strong technical support and solution to our customers.

Rigorous QC team, each LED light will be lighting 24 hours before delivery, it will ensure our general failure rate is less than 0.2%, outdoor lights failure rate less than 0.05%

Special discount and protection of sales are provided to our brand distributor.
